| Model | HK980-CCD | HK1300-CCD |
| Features | Co2 laser+CCD | |
| Laser Power | 50W | 80W |
| Paper feed width | 980mm | 1390mm |
| Carving width | 800mm | 1200mm |
| Carving length | Infinite Length | |
| Engraving thickness | ≤1mm | |
| Paper feeding system | Segmented Knurled Aluminum Shaft/Integrated Steel Spike Shaft | |
| Paper pressing device | Double spring adjustable pressure bar set | |
| Drive method | Stepper motor | |
| Carving speed | 10-800mm/s | |
| Laser current | 0-30mA | |
| Working voltage | 220V±10% 50/60Hz | |
| Machine Power | 400-450W | |
| Interface Types | USB port,、USB drive,、WIFI | |
| Output Software | AutoLaser、CorelDRAW、signmaster、CAD、AI | |
| Working Environment |
Temperature Range: +1°C to +35°C (±1°C tolerance) Humidity Range: 10% to 50% RH (Non-condensing) |
|
