No air compressor required!
The easy purge system allows for quick cleanup and consistent pre-treatment quality – day in and day out. Easier cleanup means better pre-treatment and better prints and more time to spend on the important things in your business. It doesn’t just work with DTG brand printers, virtually any brand of pretreatment will work in our Machine. With simple speed control settings you can lay down as little or as much pre-treatment as you like.
Small Compact Design 35.8″ x 20″ x 25.2″ that can fit anywhere!
Advantage:
1. American original nozzleMake sure sprayed
2. Independent cleaning button and liquid switch, can clean the nozzle quickly.
3. Unique opening design, can place the t-shirt more Conveniently and quickly.
Specification:
Dimensions: 35.8" L x 20" W x 25.2" H / 91cm(L) X 51cm(W) X 64cm(H)
Weight: 154 lbs / 70 kg
Nozzle: Single nozzle (Imported from USA)
Max sprayed area: 16" x 21.2" / 41 cm x 54 cm
(Additional Platen at the size of 17.7" x 23.6" / 45cm x 60cm. Contact us for price and availability.)
Length adjustable range: 0-21.2" / 0-54 cm
Sprayed flux: 13-80 ml
Power: AC110 , 60HZ, 150W
Features:
Details:
*Operational considerations：
1.It is recommended to clean the nozzle after using the spray machine as soon as possible.
2.When the treatment liquid is less than 20%, then we need to add the treatment liquid in time. Otherwise a large amount of air will enter the pipeline, and the pump doesn't work.Then we need use the syringe to pull the air out of the pump.
3.It is necessary to regularly apply butter or lubricating oil to moving metal parts such as linear guide rails.
4.For more instructions, please refer to the user manual.
Customer's Case:
Package:
Packing size: 38.6" x 23.6" x 31" / 98 x 60 x 79 cm
Gross weight: 176lbs /80 kg
